HD 4CH CCTV system 1.0MP 720P camera Real time Surveillance AHD DVR KIT 4PCS outdoor 2500TVL Security Camera System 1TB HDD

HD 4CH CCTV system 1 0MP 720P camera Real time Surveillance AHD DVR KIT 4PCS outdoor
Click to see details
HD 4CH CCTV system 1 0MP 720P camera Real time Surveillance AHD DVR KIT 4PCS outdoor
100 % of buyers enjoyed this product!
Availability: in stock
TODAY'S DEAL Ends in: 04:36:18
Price:  US $295.98 / piece
Sale price:  US $192.39 / piece


from AliExpress

45 days Money back 45 days Money back Returns accepted if product not as described, buyer pays return shipping; or keep the product & agree refund with seller.
On-time Delivery On-time Delivery
Guarantees: On-time Delivery 60 days

Share:

  • 1 X 4CH AHD H.264 Full 960P DVR NVR HVR 3 IN 1 Digital Video Recorder
  • 4 x HD AHD 960P 1/3″ inch Color CCD indoor outdoor IR Day Night vision waterproof cameras
  • 4 X 65feet(20m) cctv video cable for camera
  • 1 x power adapter for cameras
  • 1 x power adapter for DVR
  • 1 X 1 to 4 power splitter cable
  • 1 X USB Mouse for DVR
  • 1 X Software CD for DVR
  • 1 X Remote Control for DVR
  • 1TB Hard disk included!!!

  • AHD (Analog High Definition) is a newly developed solution for transmitting full HD digital video in a surveillance system. The core concept of AHD is to deliver high definition video using digital TV (DTV) transmission. With AHD, high definition digital video can be transmitted easily over coaxial cables, twisted pairs, or simply over the air. Multiple 1080p30 and 1080p60 video streams can be easily transmitted using AHD over a single 5C2V/RG6 cable up to a length of 1000 meters without any repeater ( Up to 500 meters in case of 3C2V/RG59 ).
  • In the world of analog TV, The composite video baseband signal (CVBS) is the most commonly used signal format. Its popularity, ease of use, and robustness have made it an integral part of our lives. CVBS is in fact a de facto signal standard for analog video surveillance systems. As we bid farewell to analog TV with worldwide analog switch-off (ASO) and move on to the age of digital TV, digital technologies, such as DVB-T, ISDB-T, and ATSC, became popular and indispensable much like CVBS in the analog age. AHD leverages the extremely robust AV transmission capability of DTV to easily and seamlessly upgrade an analog cctv surveillance system to digital full HD. It is expected AHD to become a de facto standard for digital video surveillance systems in the future.
  • This AHD DVR has 4 channels and is a fully integrated DVR that records in real time. A remote control and mouse are included for easy setup and operation. With features like network access, VGA video output, HDMI 1080p output.and USB2.0 backup, you will find this DVR perfect for your home or small business.
  • These bullet cameras are designed for both outdoor and indoor, and can be easily mounted.
  • Installation is easy and hassle free – just plug and play.
  • Very reliable operation, long operating life, and premium performance at an affordable price.

It is very easy to install, you can do it by yourself.

  • 960P HD See Bigger Wider and Sharper

AHD offers you a high difinition quality resolution:1280X960,monitoring has never been easier or clearer.
Unlike expensive 960P NVR or POE system,AHD has lower price but HD quality.You’ll get more than paid for.

  • AHD/DVR /NVR /HVR 3 IN 1

4CH AHD DVR System Support: AHD/DVR / HVR / NVR 3 IN 1

What is DVR /NVR /HVR 3 in 1? DVR:Digital Video Recorder. NVR:Network Video Recorder. HVR:High Definition / Hybrid Digital Video Recorder. This 3 in 1 DVR has mature technology of DVR as well as the high definition and network advantages of NVR. Save the huge cost when you want to upgrade the dvr system to be NVR!!! 720P or 1080P IP Cameras supported(ONVIF Protocal)to get high definition image

  • P2P Cloud Access via Smart Handsets

JUST TWO STEPS TO FINISH THE SETUP!!
Say Goodbye to DDNS and portforwarding.

1> Connect the Camera to DVR

2> Connect the DVR to Network

3> Scan QR for Mobile APP

4> Scan QR for S/N via APP and Enjoy Live Viewing

  • e-Cloud Access via Smart Handsets

  • Check in from anywhere,anytime

Even when you’re miles away, keep an eye on your home, kids and mischievous pets in True life HD

  • Support HDMI 1080p output

The DVR is configured the VGA and HDMI(1080p) connector.
You can connect diretly to high-definition televisions,computer monitors,it is so easy and Convenient.

  • View from a TV or PC monitor

A TV can be used with an AV cable, while a PC monitor can be used with a VGA cable,This gives you more connection options while viewing activity captured by your cameras.

  • Advanced Motion Detection Recording

The motion detection options allow you to record only when motion is detected to save hard drive space without missing important events.
You can even ensure that false alarms are avoided by setting the motion detection”mask”to block areas with constant movement.

  • Instant Email Alerts

DVR will send you email automatically if there is any motion detected to keep your home safe and soud.

  • HDMI & Easy USB Back Up

A Built-in USB port gives you the option of backing up and transferring your video footage to a USB flash drive or extremal USB hard drive.

  • Support onvif protocol

  • Supports Multiple Languages

Multi-language menus option up to 28 kinds of Language..

  • Phone one key remote operation

VCR playback remote monitoring through mobile terminals such as PC to watch Alarm and remote control and operation accept.

  • Motion Detection Alarm

When the camera to shoot someone stealing your belongings,will send photos via email to your phone,so So you are not at home,peace of mind…

  • H.264 HD Video Compression

Compared with other existing video coding standards,Provide better image quality under the same broadband.

  • Multiple Viewing options

Can support PC and TV monitoring with VGA or BNC cable.
Support VGA Output& HDMI Output.

NOTICE: This camera must be connected via AHD DVR ,Thank you .

Best choice for project reconstruction!!You can upgrade an existing analog security system

to 1.0MP/1.3MP HD camera system without changing cable routes.

1) Applying high performance sensor, the image is clear and delicate

2) Support IR-CUT dual filter switch, to achieve day and night monitoring, color is not partial or distortion

3) Analog HD 960P @AHD video output

4) Support OSD menu, can be freely adjusted in image and function

5) Transmission distance up to 500 meters

6) Support ultra low illumination

7) Support automatic electronic shutter function, adapting different monitoring environment

8) IR distance : 35 meters

9) Camera lens choices : 3.6mm

IR Cut Filter Provides accurate color reproduction in all lighting conditions.

See more details with 3.6mm/6mm lens

Day & Night Monitoring with Built-in IR-Cut filter

IP66 Professional outdoor weatherproof

Indoor/Outdoor Applicable(Camera performs both in outdoor and Indoor applications).

AHD 960P DVR Specifications

System Operating system Embedded LINUX operating system
Display Operation interface 16 bit real color GUI interface support mouse operation
Display 1/4CH
Video Video standard PAL(625 lines,50fps);NTSC(525lines,60fps)
Compression H.264(High Profile)
Display quality Monitor:960P;VGA:1280*1024;HDMI(1920*1080P)
Playback quality 960P/720P/960H/D1
Record Resolution& Frame PAL: 960P/720P/960H/ D1@100fps
NTSC:960P/720P/960H/D1@120fps
Playback Frame PAL: 960P/720P/960H/ D1@100fps
NTSC:960P/720P/960H/D1@120fps
AHD mode input 4*960p(analog) / 4*960h(analog)/2*960p(analog+2*720p(digital)
Motion detection 192(16*12)detection area;can set multi-level of flexibility
Audio Audio compression G.711A
Record and playback Record mode Manual,alarm,motion detection,timing
Local playback 4CH 960P/720P/960H/D1
Video search Time,date,event,channel search
Storage and back up Space occupation Video:CIF 4~5G/day*channel, D1 16~20G/day*channel;
Audio:691.2M/day*channel
Video storage Local HDD ,Network
Back up mode Network backup,USB portable HDD,USB DVD-RW
Network Protocol DHCP,PPPOE,FTP,DNS,DDNS,NTP,UPNP,EMAIL etc
IE Browser Windows IE ,Firefox ,Chrome ,Safari etc.
CMS Free use
Mobile Phone Android\ iPhone\ iPad\ Blackberry\ Windows Mobile
Interface Video input 4CH BNC
Video output 1CH BNC,1CH VGA,1CH HDMI 1080p
Audio input 4CH RCA
Audio output 1CH RCA
Network port RJ45 10M/100M Ethernet port
PTZ control 1 RS485;support multi kinds of PTZ Protocol
USB port 2*USB2.0
HDD port 1 SATA(each max support 3TB)
other Language English,Finnish,French,German,Greek,Italian,Japanese ,Polish,Portuguese,Arabic,Farsi,Russian,Spanish,Thai,Turkish, etc
Mouse yes
Remote controller yes
Power DC12V/2A
Dimension 250(L) x 235(W) x 45(H)

HD AHD 960P Camera Specifications

Sensor 1/3″inch imx238
Signal System PAL/NTSC
Video Standard AHD
DSP NVP2431H
Camera type High performance AHD Camera
Effective Pixel PAL : 1280*960@25fps NTSC : 1280*960@30fps
Active Pixel 1280*960
Resolution 1.3 Mega Pixel 960P
Video output AHD/CVBS||PAL/NTSC
Minimum Illumination 0.01Lux(F1.2)
Gama adjust 0.45
Lens 3.6mm(6mm optional)
IR LEDs Amount 36pcs infrared LEDs
IR-CUT Auto switch
IR Distance 30M
Electric Shutter 1/53~1/100000s
S/N Ratio 50dB(min)(AGC closed)
3D-NR OFF/LOW/MID/HIGH
2D-NR OFF/LOW/MID/HIGH
HLC Support
WHITE Balance ATW/AWC-SET/Indoor/Outdoor/MANUAL
AGC Level 0-15
D-WDR Auto
Sens-UP X2-X30
Day/Night Auto,Color,B/W,Ext
Power Supply DC 12V
Power Dissipation 300mA
Operation Temperature Temperature -25°F~122°F / -32°C ~60°C,Humidity less than 85%RH
Dimension 18.4(L)*6.5(H)CM
