Rico Board AM4378 Development Board TI Cortex-A9 AM4378 Development Board(1GHz TI AM4378 Sitara ARM Processor,1G RAM,16MB Flash)
 |
45 days Money back Returns accepted if product not as described, buyer pays return shipping; or keep the product & agree refund with seller. |
|---|---|
 |
On-time Delivery Guarantees: On-time Delivery 60 days |
-Product Description-
Rico Board AM4378 Development Board TI Cortex-A9 AM4378 Development Board(1GHz TI AM4378 Sitara ARM Processor,1G RAM,16MB Flash)
-Over View- The Rico Board is an excellent high-performance Single Board Computer (SBC) using the newest TI’s AM437x Sitara ARM Cortex-A9 based solution. This new generation solution has an increase in performance, as well as extensive reuse from the ARM Cortex-A8 offerings. It features up to 1GHz of processing power, 3D graphics acceleration for rich graphical user interfaces, PRU-ICSS for industrial protocols, improved Vector Floating Point (VFP) unit and other peripherals and interfaces support like Quad-SPI, dual parallel cameras, two independent eight-channel ADCs, etc.
Rico Board – TI AM437x ARM Cortex-A9 Single Board Computer The AM437x processor family has four different pin-to-pin compatible AM437x device variations: the Sitara AM4376, AM4377, AM4378 and AM4379. They only have differences in options whether they have offered 3D graphics accelerator and their PRU can support for the EtherCAT slave protocol. Users can make selections according to their requirements.
TI AM437X Devices The Rico board is equipped with 512MB DDR3, 4GB eMMC Flash, 16MB QSPI Flash and 32KB EEPROM on board. Additionally, it has rich peripherals including a Debug serial port, USB 2.0 Host and Device ports, a Gigabit Ethernet port, TF card slot, HDMI port, dual camera interfaces, LCD interface, etc. Two 2.54mm pitch 40-pin expansion connectors allow the availability of more I/Os for peripheral signals like two SPI, two I2C, two CAN, four UARTs, one MMC and eight-channel ADC. The Rico Board is capable of running Linux operating system and provided with Linux 3.12.10 SDK of which the kernel and many drivers are in source code. MYIR also offer a complete Rico Board development kit that includes a Rico Board, necessary cable accessories, an optional 7-inch LCD Module (including capacitive touch screen), optional 3G, WiFi, Camera and GPRS modules, and detailed documents to enable rapid development when customers getting the board out-of-the-box. The Rico Board can be used for the evaluation module (EVM) for the AM437x processor family; it can also be used directly for your embedded products. Typical applications are industrial automation, Programmable Logic Controllers (PLCs), bar code scanners, portable data terminals, test and measurement, patient monitoring and human machine interface (HMI). The Rico Board has been selected as the Host Controller Board for TI’ TIDA-00750 People Counting Demand Controlled Ventilation 3D Time-of-Flight (ToF) Reference Design due to its affordable cost, ready-to-use interfaces and Debian supporting.
TIDA-00750 People Counting for Demand Controlled Ventilation Using 3D Time-of-Flight (ToF) Reference Design Board Image -Features-
| – POWERVR SGX Graphics Accelerator subsystem for 3D graphics acceleration to support display and gaming effects | |
| – Single-cycle vector floating point (VFP) | |
| – Dual camera and display processing subsystem | |
| – Cryptographic acceleration and secure boot | |
| – PRU-ICSS enables simultaneous industrial Ethernet protocols and motor feedback protocols | |
| – Support for 32 bit LPDDR2/DDR3/DDR3L | |
| – Low power: ~5mW deep sleep and < 0.1mW RTC-only | |
| – Simplified power sequence for flexible power designs | |
| Memory | 512MB DDR3 SDRAM (2 x 256MB, 32-bit), compatible with 256MB/1GB DDR3 SDRAM |
| Storage | 4GB eMMC |
| 256/512MB Nand Flash (reserved) | |
| 16MB QSPI Flash | |
| 32KB EEPROM | |
| TF card interface | |
| Communications | 1 x Debug serial port |
| 1 x 10/100/1000M Ethernet | |
| 1 x Mini USB 2.0 Device port | |
| 1 x USB Host 2.0 port | |
| Display | 1 x HDMI interface |
| 1 x LCD interface | |
| Input and Output | 1 x 1.27mm pitch 20-pin JTAG interface (not soldered, on the back of the board) |
| 2 x 30-pin Camera Interfaces | |
| 4 x Buttons (1x Reset, 2 x User, 1 x Power) | |
| 5 x LEDs (3 x User LEDs, 1 x Power indicator, 1 RGB LED) | |
| Others | 2 x 2.54mm pitch 40-pin female expansion connectors brought out peripherals below: |
| – 2 x SPI | |
| – 2 x I2C | |
| – 2 x CAN | |
| – 4 x UARTs | |
| – 1 x MMC | |
| – 8 x ADC | |
| Dimensions | 65mm x 100mm x 1.6mm (8-layer PCB design) |
| Power supply | USB power supply or DC 5V/2A |
| PMIC | Power Management IC (TPS65218) |
| Working Temp. | 0~70 Celsius |
| OS support | Linux 3.12.10 |
-Package List-
Rico Board(MYS-4378-100-C-S) x1
DVD x1
